C-47 Dakota Landing Gear
Note cast item with circular holes is part of the brace/support frame for the lowering/detract hydraulic ram on main gear for a C-47
1. Shock Absorber Strut
3. Landing Gear Upper Truss
5. Rear Brace Strut
Credit: C-47 Erection & Maitence Manual Date:
